OMRON expands popular screw-terminal relay series for high-current applications
OMRON Electronic Components Europe has introduced G9EK-1-EX DC power relays with 250A/500VDC switching rating for safety isolation in electric-vehicle charging infrastructure, renewable energy, and e-mobility applications.
Extending the G9EK screw-terminal series, the normally-open relays leverage an optimized internal structure that has contact resistance of only 15mΩ when closed and coil consumption of just 4W. By combining low power consumption and dissipation with greater switching current, in the 47.7mm x 86mm x 64.2mm high outline of other G9EK-1 relays, the G9EK-1-EX provides an efficient and space-saving alternative to high-current contactors. With its 250A/500VDC switching rating, the G9EK-1-EX expands the application reach and enhances safety margin compared to the G9EK-1-E, which is rated for 200A/500VDC.
The G9EK-1-EX contact mechanism provides enhanced tolerance to shock and vibration, withstanding shocks up to 100g for superior safety and reliability in e-mobility applications including industrial autonomous guided vehicles (AGVs). In addition, the G9EK-1-EX terminal structure minimizes magnetic repulsive forces generated by large currents during conditions such as short circuits, ensuring longer lifetime and greater reliability.
Targeting applications that demand outstanding electrical and mechanical robustness, OMRON’s G9EK-1-EX relays handle interruption current up to 1000A at 400V and withstand voltage pulses up to 4000V. While the relays can handle superior current and voltage, their gasless design ensures safe operation and a simplified internal architecture with carbon-neutral credentials.
The G9EK-1-EX also ensures fast switching responses, with 50ms operating time and 30ms release time, as well as assured mechanical longevity of 200,000 operations.
About OMRON Electronic Components Europe
On 1 April 2022, OMRON Corporation announced that its’ Electromechanical Components (EMC) division was renamed as OMRON Device and Module Solutions (DMS) in line with the global long-term vision ″Shaping the Future 2030.”
OMRON Electronic Components Europe is the European subsidiary of the Device and Module Solutions division. The revised division name reflects a new focus on delivering solutions to customers globally and in Europe. Society is facing new social and environmental changes, and OMRON recognises and is responding to that.
The company aims to offer its’ customers solutions that help them address these universal challenges. In accordance with the long-term strategy, OMRON intends to contribute further to the roll-out of new energy sources and of high-speed communications by enabling the creation of sturdier, advanced and more efficient devices. These devices will make people’s lives easier and better, in particular by achieving carbon neutrality, realizing a digital society and extending healthy life expectancy.
OMRON Electronic Components Europe strongly supports its customers in Western and Eastern Europe through 8 regional offices, a network of local offices and partnerships with specialist, local, regional and global distributors.
About OMRON Corporation
OMRON Corporation is a global leader in the field of automation based on its core technology of „Sensing & Control + Think.” OMRON’s business fields cover a broad spectrum, ranging from industrial automation and electronic components to social infrastructure systems, healthcare, and environmental solutions. Established in 1933, OMRON has about 30,000 employees worldwide, working to provide products and services in around 120 countries and regions.
